MS-30 · 3 t
Electric Forklift 3 t
Four-wheel, 3.0 t. The smallest truck in the range that comfortably handles a 1,200 mm pallet at a 600 mm load centre without derating.
Compare MS-35 vs MS-30
MS-35 · Electric Forklift
MS-35 — 3.5 t Electric Forklift
Four-wheel, 3.5 t. Bought for brick, block and bagged material where the pallet is short but heavy.
3.5 t
Capacity
80 V / 500 Ah lead-acid or 80 V 400 Ah Li-ion
Battery
3,000 mm standard; 4,500 / 6,000 mm optional
Lift height
2285 mm
Turning radius
MS-35 in service. More photographs below.
MS-35 in service
Representative environments for this class of machine. Photographed on location, not in a studio.
Specification
| Model | MS-35 |
|---|---|
| Standard designation | CPD-35 |
| Rated capacity | 3.5 t |
| Lift height | 3,000 mm standard; 4,500 / 6,000 mm optional |
| Service weight | 4580 kg |
| Battery | 80 V / 500 Ah lead-acid or 80 V 400 Ah Li-ion |
| Tyres | Solid rubber 28×9-15 (front) / 6.50-10 (rear) |
| Turning radius | 2285 mm |
| Length | 3715 mm to fork face |
| Width | 1230 mm |
Figures are the standard build. Mast, fork length, attachment, battery and paint are fixed at order; anything not on this table is quoted rather than assumed.
What MS-35 is bought for
Four-wheel, 3.5 t. Bought for brick, block and bagged material where the pallet is short but heavy.
If the load is consistently heavier than 3.5 t, the next frame up carries the same mast and fork family, so the attachment and spare-parts stock do not have to change. If the load is lighter but the access is the constraint, the frame below is the one that fits through the door — capacity is rarely the only variable.
The size above and below
MS-40 · 4 t
Electric Forklift 4 t
Four-wheel, 4.0 t. Steps into the frame size shared with the diesel line, so masts and forks are common across both.
Compare MS-35 vs MS-40Wear parts for MS-35
The parts that fail first on this class, with the interval we see in the field.
Customer feedback
We publish feedback only with the buyer's permission and only when it is attributable — no anonymous quotes. If you would like to speak to someone running this class of machine, ask for a reference and we will arrange the call with their consent.
Quote for MS-35
Send the load, the lift height and the destination port. You get the model, the mast, the attachment and a written price.
